Digital Material Finishing Cutter Table
With decades’ of cutting knowledge and experience, we’ve never stopped improving the AOLcut. Intelligent engineering with an intuitive interface make it easy to use, easy to maintain, extremely accurate and capable of producing the highest quality cut parts the first time, every time.
When a greater number of high quality cut parts are produced with lower labor and material costs, you get more than just a solid ROI. Get the cutting system that contributes significantly to the profitability of your business.
Detailed introduction
| Type of gasket | Thickness | AOL digital cutter efficiency | Manual cutting efficiency | Instead of manual quantity |
| Graphite gasket | 1.5mm | 300mm/s | 50-100mm/s | 2 pepole |
| 2mm | 300mm/s | 50-100mm/s | 2-3 people | |
| 5mm | 100mm/s | 10mm/s | 4 people | |
| Ordinary gasket | 3mm | 300mm/s | 50-100mm/s | 2-3 people |
| 5mm | 200mm/s | 50mm/s | 2-3 people | |
| Rubber gasket | 3mm | 200mm/s | 50mm/s | 3 people |
| 5mm | 100mm/s | 10mm/s | 3 pepole | |
| 10mm | 50mm/s | ≤10mm/s | 4 pepole | |
| PTFE gasket | 3mm | 150mm/s | 10-50mm/s | 3-4 pepole |
| 5mm | 100mm/s | 10mm/s | 3-4 pepole | |
| The above data is for reference only, the actual operation, affected by the thickness, hardness, flexibility, etc. of the material, the data will be biased. | ||||
| Model | AOL-1625DCS | AOL-1825DCS |
| Working area | 2500×1600mm | 2500×1800mm |
| Machine size (mm) | 3600*2400*1250 | 3600*2600*1250 |
| Rated power | 11KW | |
| Fixed mode | Vacuum adsorption, automatic feeding type table | |
| Multifunctional head | Pneumatic knife, Milling tool, projector,vibrating knife | |
| Tool configuration | Multiple cutting knives | |
| Safety device | Using infrared sensors, responsive, safe and reliable Anti-collision system Four corner emergency stop button |
|
| translational velocity | 800-2000mm/s | |
| Cutting speed | 0-1800mm/s(according to different cutting materials) | |
| Cutting thickness | ≤50mm(according to different cutting materials) | |
| Cutting materials | Asbestos, graphite, rubber, silica gel, PTFE, expanded PTFE, pvc, cork, etc. | |
| Repeated accuracy | ±0.1mm | |
| Capacity | 2GB | |
| Transmission system | Precision grinding rack drive | |
| Instruction system | AI、PLT、DXF、PDF、 PCE、XML | |
| Other configuration | import servo motor,high precision helical gear reducer,import rail,rack,sensor,low-voltage appliances,power supply, cable,42mm adsorption platform,automatic feeding,rail,energy saving fan | |
Machine Display
Control System
Independent research and development of human-machine interface operating system, humanized design, intelligent recognition of knife cutting, fast capture of cutting targets.
Accurate and Stable Working Table
The cutting table is build with aviation aluminum with honeycomb structure inside; sturdy, high-precision, stable for long-term running.
Imported Servo Motor
The machine with more stable performance and higher precision.
Modutarized Cutting Tools
The modularized design ensures the cutting tools can be used on all the AOL product series.
The Thickness
The thickness of machine some steel plate parts is 12-20mm, it ensures the machine will be non-deformation permanently.
Diverse Tools
Oscillating Knife Tool
The Electrical Oscillating Tool is super suitable for cutting the material of medium density.Coordinated with various kinds of blades, applied for cutting different materials.
Cutting materials: kt board , foam board, honeycomb board, car mat, seat cover, corrugated, cardboard, kt board, gray board, composite materials, leather, corrugated box.
Cutting materials: kt board , foam board, honeycomb board, car mat, seat cover, corrugated, cardboard, kt board, gray board, composite materials, leather, corrugated box.
Creasing Wheel Tool
A selection of creasing tools allows for perfect creasing on the corrugated materials. Coordinated with the cutting software,the tool can cut the corrugated material along its structure or the reverse direction to have a finest creasing result,without any damage to the corrugated material's surface.
Cutting materials: Packing box, folding card, corrugated Board, carton,etc.
Cutting materials: Packing box, folding card, corrugated Board, carton,etc.
V-CUT Knife Tool
Specialized for V-cut processing on corrugated materials,AOL v-Cut Tool can cut 0°,15°,22.5°,30°and 45°.
Cutting material: soft board , kt board , corrugated board, packing box, slotting of corrugated boxes, medium-density material v cuts, carton packaging, hard cardboard, gift boxes,etc.
Cutting material: soft board , kt board , corrugated board, packing box, slotting of corrugated boxes, medium-density material v cuts, carton packaging, hard cardboard, gift boxes,etc.
Kiss-CUT Knife Tool
The kiss cut tool is mainly used for cutting vinyl materials (labels).aol cut makes it possible that the tool cuts through the top part of the material without any damage to the bottom part.It allows high cutting speed for material processing.
Cutting materials: sticker, car sticker, reflective materials, self-adhesive vinyl, label, vinyl, engineering reflective film, double-layer adhesives, etc.
Cutting materials: sticker, car sticker, reflective materials, self-adhesive vinyl, label, vinyl, engineering reflective film, double-layer adhesives, etc.
Pneumatic Knife Tool
Driven by compressed air,Pneumatic Knife Tool with 6mm stroke, is especially for cutting hard and compact materials. Equipped with different kinds of blades,it can make different process effect.The tool can cut the material up to 110mm by using specialized blades.
Cutting materials: asbestos board, asbestos free board, PTFE, rubber board , fluorine rubber board, silica gel board, graphite board, graphite composite board, etc.
Cutting materials: asbestos board, asbestos free board, PTFE, rubber board , fluorine rubber board, silica gel board, graphite board, graphite composite board, etc.
Milling Knife Tool
With imported spindle,it has a rotating speed of 60000 rpm.The router driven by high frequency motor can be applied for cutting hard materials with the maximum thickness of 22 mm.The customized cleaning device cleans up the production dust and debris.The air cooling system extends blade life.
Cutting materials: acrylic MDF board, pvc board, display stand, etc.
Cutting materials: acrylic MDF board, pvc board, display stand, etc.
Drag Knife Tool
AOL drag knife tool can perfectly cut materials with the thickness up to 5mm. Compared to other cutting tools,it is the most cost-effective one that allows for the fastest cutting speed and lowest maintenance cost.
Cutting materials: backlit film, sticker, pp paper , folding card, flexible material less than 3mm thickness, advertising materials KT board, flexible plastics, mobile phone film, etc.
Cutting materials: backlit film, sticker, pp paper , folding card, flexible material less than 3mm thickness, advertising materials KT board, flexible plastics, mobile phone film, etc.
Driven Rotary Knife Tool
Driven Rotary Tool puts the materials by the high-speed rotating blades driven by the servo motor.The tool can be installed with circular blades and decagonal blades .etc which are especially suitable for cutting woven materials.
Cutting materials: textiles, canvas, leather, fabric, carbon fabric, glass fabric, carpet, blanket, fur, woven fabric, composite double, multi-layer material, flexible plastic, etc.
Cutting materials: textiles, canvas, leather, fabric, carbon fabric, glass fabric, carpet, blanket, fur, woven fabric, composite double, multi-layer material, flexible plastic, etc.
