AOL-1070PAS serial digital cutting plotter
AOL-1070PAS serial digital cutting plotter is widely used in packaging and signs, including, paper, board, sticker, vinyl and so on. AOL-1070 digital cutter is the key equipment for small volume production and sample making. This machine provides perfect solutions for printing.

1070 cutting plotter used precise auto-positioning system: Equipped with HD CCD camera, it could achieve the precise auto-positioning of all materials and the automatic registering, which solves the imprecise manual positioning and the deforming printing, so as to reach the simple and precise cutting.
Detailed introduction

High-speed digital cutting machines are advanced cutting machines that use digital technology to cut materials such as corrugated paper, gray cardboard, PVC expansion board, honeycomb board, car stickers, EPE foam, EVA foam, soft film, flag cloth, light box, tarpaulin, KT board, PVC expansion board, acrylic, PVC board, label stickers, etc. These machines are designed to be fast and accurate, with cutting speeds of up to 1200 mm/s. They are also very efficient, with cutting accuracy up to 0.01 mm.

Imagine a complex machine equipment, each of its tiny parts is precisely designed and manufactured. These seemingly insignificant parts determine the stability and performance of the entire system. From high-precision sensors to durable alloy parts, every detail is the result of engineers' hard work day and night.

Flatbed cutters of the AOL-1070PAS are the ideal complement to existing machines. Thanks to their flexibility, they also allow for smaller orders that can only be produced uneconomically with large die-cutting systems.

Advantage of  digital cutting plotter

AOL-1070pas series cutting plotter is suitable for the sample pattern's design and manufacturing in the light, artwork, and color box industries.

Best Cost-Efficient: Integrated with cutting tool creasing wheel tool plotting pen and CCD registration system.

Automatic Positioning: Fully Automation! Integrated with camera registration, through-cut kiss-cut and creasing within one

Ideal solution for very short-run on-demand finishing jobs of prints by digital press.

Functional features: Automatic Positioning,Automatic cutting ,Automatic Feeding,Automatic ReceIving.

From individual display packaging for events to rubber, felt or silicone seals to the cutting of leather and upholstery fabrics in the furniture industry, the range of applications for industrial cutting plotters is very wide. It is also ideal for making prototypes or trial orders during product development.



Parameters of AOL-1070PAS series digital cutting plotter:

    Model      AOL-1070PAS
    Working area      1000*700mm
    Multi-function head

     Oscillating knife cutting tool, drag knife cutting tool, crease wheel,cut-through-knife,marking pen and CCD camera

    Tool configuration      Multiple cutting knives
    Cutting speed      200-1300mm/s(according to different cutting materials)
    Repeated accuracy      ≤0.1mm
    Transmission system      Imported(Digital servo motor, linear guide, belt)
    Safety device       Using infrared sensors,  responsive, safe and reliable.
    Drive system      Imported servo motor, linear guid, synchronous belt, screw
    Cutting material

     PVC board, PP board and white card paper, cardboards, paper, PVC, film, sticker, etc.

The maximum cutting depth is up to 20mm, depending on material density.

    Instruction system      HP- GL Compatible format
    Rated power      2. 2KW
    Rated voltage     220V±10%/50HZ
    Cutting thickness     ≤10mm(According to different material)
    Material fixed way     Vacuum adsorption
    File form

    PLT、DXF、HP/GL

Features of AOL-1070PAS series digital cutting plotter:

Infrared anti-collision technology:

The machine adopts "infrared anti-collision" technology, which uses the characteristics of infrared rays and does not rely on visible light to achieve effective obstacle detection and anti-collision, improving operation safety and efficiency. When the machine is working, if the human body is too close to the machine, this safety device will protect the machine and automatically suspend work to avoid injury.

High-quality synchronous belt:

Adopt high-quality synchronous belt transmission, large load-bearing capacity, high transmission accuracy, high transmission speed within a short distance, and low noise

Imported felt:

To ensure that the product has good cutting accuracy and durability, it has been finely processed and treated to ensure that the quality meets international standards.

AOL service

1)  Three-year free warranty (except vulnerable parts), free inspection and maintenance of main components.

2) Provide lifetime free technology upgrade service

3) Wearable parts (such as blades, workbench covers) are always available at cost when needed.

4) Free operation training is conducted in our factory. If there is not enough time, we will send detailed training videos.

5) 24-hour online service, providing free technical support in different languages.

6) On-site technical support can be provided when needed.

aol service

Packing details

1. Full film packaging machine (to prevent moisture)

2. Anti-collision edging

3. Wooden box packaging (standard specifications)

4. A warning sign is posted on the packaging box

packaging details of digital cutting plotter

Company Info

AOL is a famous CNC equipment factory located in Jinan, Shandong, China. AOL mainly produce CNC Knife Cutting Machine, Cutting Plotter, CNC Cutting Table and so on. We, as a high-tech enterprise, engaged in research, manufacture and sell the CNC cutting machine and relevant products.

AOL has gained CE certificate, FDA and ISO certificate. Company successfully produce AOL series products of more than 50 sorts, which enjoy good reputation and support.  Excellent quality and fast service makes our products spread all over the world as Europe, America, Middle east and South of Asia.

aol company info

AOL intelligent blade cutting machine has high precision and high efficiency. Our professional after-sales service can provide automatic cutting solutions for various industries.

For more information, please consult:

Email: info@aolcnc.com

Phone: +86-531-88620680

WhatsApp/We Chat: 0086-18560162709

youtube: https://www.youtube.com/channel/UCDiNQSjBR5DsAX9QfkWF7AA

Website: https://www.aolcutcnc.com/

Machine Display
Control System
Independent research and development of human-machine interface operating system, humanized design, intelligent recognition of knife cutting, fast capture of cutting targets.
Accurate and Stable Working Table
The cutting table is build with aviation aluminum with honeycomb structure inside; sturdy, high-precision, stable for long-term running.
Imported Servo Motor
The machine with more stable performance and higher precision.
Imported Guide Belt
The imported conveyor ensures the conveying material is smoother, with better ventilation and not deformed.
The Thickness
The thickness of machine some steel plate parts is 12-20mm, it ensures the machine will be non-deformation permanently.
CCD Sensor Auto Positioning
The camera automatically patrols the edge and cuts at high speed.
Lettering knife head
Diverse Tools
Oscillating Knife Tool
The Electrical Oscillating Tool is super suitable for cutting the material of medium density.Coordinated with various kinds of blades, applied for cutting different materials.

Cutting materials: kt board , foam board, honeycomb board, car mat, seat cover, corrugated, cardboard, kt board, gray board, composite materials, leather, corrugated box.
Creasing Wheel Tool
A selection of creasing tools allows for perfect creasing on the corrugated materials. Coordinated with the cutting software,the tool can cut the corrugated material along its structure or the reverse direction to have a finest creasing result,without any damage to the corrugated material's surface.

Cutting materials: Packing box, folding card, corrugated Board, carton,etc.
V-CUT Knife Tool
Specialized for V-cut processing on corrugated materials,AOL v-Cut Tool can cut 0°,15°,22.5°,30°and 45°.

Cutting material: soft board , kt board , corrugated board, packing box, slotting of corrugated boxes, medium-density material v cuts, carton packaging, hard cardboard, gift boxes,etc.
Kiss-CUT Knife Tool
The kiss cut tool is mainly used for cutting vinyl materials (labels).aol cut makes it possible that the tool cuts through the top part of the material without any damage to the bottom part.It allows high cutting speed for material processing.

Cutting materials: sticker, car sticker, reflective materials, self-adhesive vinyl, label, vinyl, engineering reflective film, double-layer adhesives, etc.
Pneumatic Knife Tool
Driven by compressed air,Pneumatic Knife Tool with 6mm stroke, is especially for cutting hard and compact materials. Equipped with different kinds of blades,it can make different process effect.The tool can cut the material up to 110mm by using specialized blades.

Cutting materials: asbestos board, asbestos free board, PTFE, rubber board , fluorine rubber board, silica gel board, graphite board, graphite composite board, etc.
Milling Knife Tool
With imported spindle,it has a rotating speed of 60000 rpm.The router driven by high frequency motor can be applied for cutting hard materials with the maximum thickness of 22 mm.The customized cleaning device cleans up the production dust and debris.The air cooling system extends blade life.

Cutting materials: acrylic MDF board, pvc board, display stand, etc.
Drag Knife Tool
AOL drag knife tool can perfectly cut materials with the thickness up to 5mm. Compared to other cutting tools,it is the most cost-effective one that allows for the fastest cutting speed and lowest maintenance cost.

Cutting materials: backlit film, sticker, pp paper , folding card, flexible material less than 3mm thickness, advertising materials KT board, flexible plastics, mobile phone film, etc.
Driven Rotary Knife Tool
Driven Rotary Tool puts the materials by the high-speed rotating blades driven by the servo motor.The tool can be installed with circular blades and decagonal blades .etc which are especially suitable for cutting woven materials.

Cutting materials: textiles, canvas, leather, fabric, carbon fabric, glass fabric, carpet, blanket, fur, woven fabric, composite double, multi-layer material, flexible plastic, etc.
